AERMEC 2502 User Manual

INSPY. 1003. 4138305_03
26
NS Vers. U.M. 6003 6303 6603 6903 7203
EXPANSION TANK
Capacity
-
dm
3
25
Calibration pressure Bar 1.5
Quantity n° 6
SOUND DATA
Sound power
°
dB(A)
101 101 101 102 102
L 9393939394
Sound pressure
° 67,9 67,8 67,8 68,7 68,7
L 59,9 59,8 59,8 59,7 60,7
Sound power
A 101 101 101 102 102
E 9393939394
Sound pressure
A 67,6 67,5 67,5 68,4 68,4
E
59,6 59,5 59,5 59,4 60,4
DIMENSIONS°/L
Height All
mm
2450 2450 2450 2450 2450
Width
°/L
2200 2200 2200 2200 2200
Depth 11530 12520 12520 13510 13510
Weight when empty
Kg
11390 12210 12250 13230 13570
Weight when empty with desuper-
heater
11520 12360 12410 13400 13750
Weight when empty with total heat
recovery
12237 13079 13152 14154 14527
Weight during operation 11703 12555 12654 13666 14065
DIMENSIONS A/E
Height All
mm
2450 2450 2450 2450 2450
Width
A-E
2200 2200 2200 2200 2200
Depth 14490 15470 15470 16450 16450
Weight when empty
Kg
13760 14330 14560 14970 15350
Weight when empty with desuper-
heater
13900 14480 14710 15140 15530
Weight when empty with total heat
recovery
14607 15199 15462 15894 16307
Weight during operation 14151 14773 15003 15465 15845
Sound power
Aermec determines the sound power value on the
basis of measurements taken in accordance with
standard 9614-2, in compliance with the Eurov-
ent certification.
Sound pressure
Sound pressure in an unrestricted range on a reflec-
tive plane (directional fact. Q=2), 10m away from
the unit external surface, complying with ISO 3744.

AERMEC 2502 Specifications

General

Brand	AERMEC
Model	2502
Category	Chiller
Language	English
