AERMEC 2502 User Manual

INSPY. 1003. 4138305_03
66
19.9. CARPENTRY BY 10120 (mm)
NS 3902 - -4202
°°(A/E°°00…PA…PK)
WARNING:
ALWAYS USE ALL THE
PROVIDED EYEBOLTS
FOR THE LIFTING OF
THE UNIT
1
7
8
9
10 12 14
16
13 1511
2
3
4
5
6
POSITION OF VIBRATION DAMPERS
POSITION FOR LIFTING
NS
Heat recovery
Version
Hydronic kit
(1)
Weight and centre
of gravity
when empty
(kg)
Support 1 Support 2 Support 3 Support 4 Support 5 Support 6 Support 7 Support 8 Support 9
Support 10 Support 11
Support 12 Support 13 Support 14 Support 15
Support 16
Kit AVX
kgx y %%%%%%%%%%%%%%%%
3902 ° A/E 00 9180 4370 1216 5.4 6.7 12.2 15 / / 2.5 3.1 6.8 8.4 10.7 13.2 3.2 3.9 4.0 4.9 519
4202 ° A/E 00 9410 4500 1215 5.3 6.6 11.8 14.6 / / 2.4 3.0 6.7 8.2 10.8 13.4 3.6 4.4 4.1 5 519
3902 D A/E 00 9280 4370 1216 5.4 6.7 12.2 15 / / 2.5 3.1 6.8 8.4 10.7 13.2 3.2 3.9 4.0 4.9 519
4202 D A/E 00 9500 4500 1215 5.3 6.6 11.8 14.6 / / 2.4 3.0 6.7 8.2 10.8 13.4 3.6 4.4 4.1 5 519
3902 T A/E 00 9960 4370 1216 6.2 7.5 12 14.5 0.9 1.1 2.3 2.8 10.6 12.8 9.1 11 1.2 1.4 3 3.6 520
4202 T A/E 00 10190 4726 1205 6.2 7.5 12 14.5 0.9 1.1 2.3 2.8 10.6 12.8 9.1 11 1.2 1.4 3 3.6 520
(1) the weight of the
pumps to be added
to the version without
hydronic kit
− PA 69 Kg
− PB 138 Kg
− PC 75 Kg
− PD 150 Kg
− PE 91 Kg
− PF 182 Kg
− PG 100 Kg
− PH 200 Kg
− PJ 108 Kg
− PK 216 Kg
Lato evaporatori
Lato compressori
Lato evaporatori
Lato compressori
Lato evaporatori
Lato compressori
0
x
y
YG
XG
1
2
3
5
7
4
6
8
9
11
13
15
10
12
14
16
17
19
21
23
18
20
22
24
