AERMEC 2502 User Manual

INSPY. 1003. 4138305_03
51
NS
°/L
Heat recovery
Version
Hydronic kit
(1)
Weight and centre
of gravity when
empty (kg)
Support 1 Support 2 Support 3 Support 4 Support 5 Support 6 Support 7 Support 8
Kit AVX
kgx y%%%%%%%%
2101 ° °/L 00 4230 1809 1247 10 13 26 35 / / 7 9 506
2401 ° °/L 00 4570 1862 1224 10 13 28 34 / / 7 8 506
2002 ° °/L 00 4270 2097 1254 7 10 25 33 / / 11 14 504
2202 ° °/L 00 4770 2015 1274 8 12 23 31 / / 11 15 505
2352 ° °/L 00 4800 2130 1287 7.5 10.5 23.2 32.7 / / 10.8 15.2 505
2502 ° °/L 00 4900 2128 1288 7.5 10.6 23.2 32.8 / / 10.8 15.2 505
2101 D °/L 00 4280 1809 1247 10 13 26 35 / / 7 9 506
2401 D °/L 00 4630
1862
1224 10 13 28 34 / / 7 8 506
2002 D °/L 00 4310 2097 1254 7 10 25 33 / / 11 14 504
2202 D °/L 00 4790 2015 1274 8 12 23 31 / / 11 15 505
2352 D °/L 00 5190 2595 1255 11 14 12 16 11 15 9 12 511
2502 D °/L 00 5360 2585 1238 10 14 13 16 12 15 9 11 511
2101 T °/L 00 4590 1826 1239 9.5 12.3 27.7 35.7 / / 6.4 8.4 506
2401 T °/L 00 5080 1845 1215 9.1 11.2 29.2 36 / / 6.5 8 506
2002 T °/L 00 4720 2138 1234 6.6 8.4 26.6 34.0 / / 10.7 13.7 505
2202 T °/L 00 5200 2099 1213 8.4 10.4 25.1 30.9 / / 11.3 13.9 505
2352 T °/L 00 5870 2578 1227 10.2 12.8 13.3 16.8 12.2 15.4 8.5 10.8 511
2502 T °/L 00 6000 2577 1224 10.2 12.8 13.4 16.9 12.2 15.4 8.5 10.6 511
NS
A/E
Heat recovery
Version
Hydronic kit
(1)
Weight and centre
of gravity when
empty (kg)
Support 1 Support 2 Support 3 Support 4 Support 5 Support 6 Support 7 Support 8
Kit AVX
kgx y%%%%%%%%
1801 ° A/E 00 4330 1830 1235
10 13 27 34 / / 7 9 506
1802 ° A/E 00 3900 2082 1218 9 11 25 31 / / 11 13 504
1801 D A/E 00 4370 1830 1235 10 13 27 34 / / 7 9 506
1802 D A/E 00 3940 2082 1218 9 11 25 31 / / 11 13 504
1801 T A/E 00 4680 1844 1229 9.5 12.1 27.8 35.2 / / 6.8 8.6 506
1802 T A/E 00 4340 2093 1202 7.8 9.4 26.7 32.2 / / 10.8 13.1 504
(1) the weight of the pumps to be add-
ed to the version without hydronic kit
− PA 69 kg
− PB 138 kg
− PC 75 kg
− PD 150 kg
− PE 91 kg
− PF 182 kg
− PG 100 kg
− PH 200 kg
− PJ 108 kg
− PK 216 kg
Lato evaporatori
Lato compressori
Lato evaporatori
Lato compressori
Lato evaporatori
Lato compressori
0
x
y
YG
XG
1
2
3
5
7
4
6
8
9
11
13
15
10
12
14
16
17
19
21
23
18
20
22
24
