AERMEC 2502 User Manual

INSPY. 1003. 4138305_03
63
19.7.1. POSITION WATER CONNECTIONS
NS 3902 -4202 °°(°/L°°00…PA…PK)
KEY
1. OUT Evaporator 4"
2. IN Evaporator 4"
3. IN Pumps 4"
All connections are VICTAULIC supplied
together with joints to weld
KEY
1. OUT Evaporator 4"
2. IN Evaporator 4"
3. IN Pumps 4"
All connections are VICTAULIC supplied
together with joints to weld
19.7.2. POSITION WATER CONNECTIONS
NS 3402 °°(A/E°°00…PA…PK)
2101 1801
934
934 506 1940
1536
910
3380
2
3
1
758 pump G/H/J/K
778
pump A/B/C/D/E/F
758
366
4370
857 1551
1962
1962 1526 882
3
1
2
710
337
710 pump G/H/J/K 730 pump A/B/C/D/E/F
974 1756 1640
910974 2486
710
337
4370
934
934
506 1940
3380
1536 910
Attacchi idraulici evaporatore versione «PA...PK»
Attacchi idraulici evaporatore versione «00»
710
337
710 pump G/H/J/K 730 pump A/B/C/D/E/F
710 pump G/H/J/K 730 pump A/B/C/D/E/F
FOR EVAPORATOR connections version «00»
FOR PUMP connections ver «PA...PK»
FOR EVAPORATOR connections version «00»
FOR PUMP connections ver «PA...PK»
IN Desuperheater Ø 2”
OUT Desuperheater Ø 2”
HYDRAULIC CONNECTIONS
IN DESUPERHEATER Ø 2"
OUT DESUPERHEATER Ø 2"
ATTACCHI IDRAULICI
POSITION AND HYDRAULIC CONNECTIONS
DESUPERHEATER BIMODULE
