Page #11 background image
11
A
D
CB
Mod. A B C D
VT9 40 30 23 M8
1000
194
97
354
310
900
69
113
OUT 1”¼
IN1”¼
650
330
Ø 9
895
122,50 122,50
Gx
Gy
OUT 1”¼
IN 1”¼
A
C
B
D
DIMENSIONS (mm) / POSITION OF HYDRAULIC CONNECTIONS
ANL 021 ÷ 041 VERSIONS °/P
