21.01 5723611_01 23
Size 151 201 281 302 332 352 382 502 552 602
4 A,E % 19% 21% 21% 19% 19% 19% 0% 0% 0% 0%
5 A,E % - - - - - - 20% 20% 19% 23%
6 A,E % - - - - - - 19% 19% 19% 24%
INTEGRATED HYDRONIC KIT: 02, 04, 06, 08
Weights
Layout A,E type 1 2 2 2 2 2 3 3 3 4
Weight empty + packaging A,E kg 946 1031 1031 1120 1165 1166 1243 1250 1272 1476
Centre of gravity (empty)
X A,E mm 1029 1288 1288 1225 1240 1239 1440 1439 1419 1770
Y A,E mm 552 554 554 539 540 539 545 546 542 550
Weight distribution in % on the supports (empty)
1 A,E % 30% 29% 29% 31% 30% 30% 30% 30% 31% 26%
2 A,E % 30% 29% 29% 29% 29% 29% 30% 30% 30% 26%
3 A,E % 20% 21% 21% 20% 21% 21% 0% 0% 0% 0%
4 A,E % 20% 21% 21% 19% 20% 20% 0% 0% 0% 0%
5 A,E % - - - - - - 20% 20% 20% 24%
6 A,E % - - - - - - 20% 20% 19% 24%
INTEGRATED HYDRONIC KIT: 09, I1, I2, I3, I4, K1, K2, K3, K4, W1, W2, W3, W4
Weights
Layout A,E type c.s. c.s. c.s. c.s. c.s. c.s. c.s. c.s. c.s. c.s.
Weight empty + packaging A,E kg c.s. c.s. c.s. c.s. c.s. c.s. c.s. c.s. c.s. c.s.
Centre of gravity (empty)
X A,E mm c.s. c.s. c.s. c.s. c.s. c.s. c.s. c.s. c.s. c.s.
Y A,E mm c.s. c.s. c.s. c.s. c.s. c.s. c.s. c.s. c.s. c.s.
Weight distribution in % on the supports (empty)
1 A,E % c.s. c.s. c.s. c.s. c.s. c.s. c.s. c.s. c.s. c.s.
2 A,E % c.s. c.s. c.s. c.s. c.s. c.s. c.s. c.s. c.s. c.s.
3 A,E % c.s. c.s. c.s. c.s. c.s. c.s. c.s. c.s. c.s. c.s.
4 A,E % c.s. c.s. c.s. c.s. c.s. c.s. c.s. c.s. c.s. c.s.
5 A,E % c.s. c.s. c.s. c.s. c.s. c.s. c.s. c.s. c.s. c.s.
6 A,E % c.s. c.s. c.s. c.s. c.s. c.s. c.s. c.s. c.s. c.s.
INTEGRATED HYDRONIC KIT: P1, P3
Weights
Layout A,E type 1 2 2 2 2 2 3 3 3 4
Weight empty + packaging A,E kg 891 970 970 1060 1104 1105 1172 1178 1200 1406
Centre of gravity (empty)
X A,E mm 1063 1244 1244 1181 1198 1197 1437 1436 1415 1728
Y A,E mm 555 557 557 541 542 541 548 549 545 552
Weight distribution in % on the supports (empty)
1 A,E % 29% 29% 29%
32% 31% 31% 30% 30% 31% 27%
2 A,E % 29% 30% 30% 31% 30% 30% 30% 30% 30% 27%
3 A,E % 21% 20% 20% 19% 20% 20% 0% 0% 0% 0%
4 A,E % 21% 21% 21% 19% 19% 19% 0% 0% 0% 0%
5 A,E % - - - - - - 20% 20% 20% 23%
6 A,E % - - - - - - 20% 20% 19% 23%
INTEGRATED HYDRONIC KIT: P2, P4
Weights
Layout A,E type 1 2 2 2 2 2 3 3 3 4
Weight empty + packaging A,E kg 932 1018 1018 1108 1152 1153 1212 1218 1240 1446
Centre of gravity (empty)
X A,E mm 1104 1280 1280 1217 1231 1230 1476 1474 1453 1768
Y A,E mm 553 554 554 539 540 540 546 548 544 551
Weight distribution in % on the supports (empty)
1 A,E % 28% 29% 29% 31% 31% 31% 29% 29% 30% 26%
2 A,E % 28% 29% 29% 30% 29% 29% 29% 29% 29% 26%
3 A,E % 22% 21% 21% 20% 20% 20% 0% 0% 0% 0%
4 A,E % 22% 21% 21% 19% 20% 20% 0% 0% 0% 0%
5 A,E % - - - - - - 21% 21% 21% 24%
6 A,E % - - - - - - 21% 21% 20% 24%
c.s. = contact the factory
Weight distribution and centres of gravity during operation
Size 151 201 281 302 332 352 382 502 552 602
INTEGRATED HYDRONIC KIT: 00
Weights
Layout A,E type 1 2 2 2 2 2 3 3 3 4
Weight functioning A,E kg 825 897 897 988 1032 1033 1099 1108 1130 1336
Centre of gravity (during operation)
X A,E mm 1006 1213 1213 1149 1169 1168 1386 1385 1364 1662
Y A,E mm 605 607 607 584 583 583 583 584 579 583
Weight distribution in % on the supports (during operation)
1 A,E % 28% 28% 28% 31% 30% 30% 27% 27% 28% 12%
2 A,E % 35% 34% 34% 35% 34% 34% 30% 30% 31% 13%
3 A,E % 17% 17% 17% 16% 17% 17% 5% 5% 5% 27%
4 A,E % 20% 21% 21% 19% 19% 19% 6% 6% 5% 30%
