24 21.01 5723611_01
Size 151 201 281 302 332 352 382 502 552 602
5 A,E % - - - - - - 15% 15% 15% 8%
6 A,E % - - - - - - 17% 17% 17% 10%
INTEGRATED HYDRONIC KIT: 01, 03, 05, 07
Weights
Layout A,E type 1 2 2 2 2 2 3 3 3 4
Weight functioning A,E kg 1163 1239 1239 1330 1374 1375 1551 1560 1582 1785
Centre of gravity (during operation)
X A,E mm 1043 1351 1351 1294 1304 1303 1544 1543 1526 1955
Y A,E mm 539 541 541 528 530 529 532 533 530 536
Weight distribution in % on the supports (during operation)
1 A,E % 31% 28% 28% 30% 30% 30% 20% 20% 20% 8%
2 A,E % 30% 27% 27% 28% 28% 28% 18% 18% 19% 7%
3 A,E % 20% 22% 22% 22% 22% 22% 17% 17% 17% 31%
4 A,E % 19% 22% 22% 20% 20% 20% 16% 16% 16% 29%
5 A,E % - - - - - - 15% 15% 15% 13%
6 A,E % - - - - - - 14% 14% 14% 12%
INTEGRATED HYDRONIC KIT: 02, 04, 06, 08
Weights
Layout A,E type 1 2 2 2 2 2 3 3 3 4
Weight functioning A,E kg 1202 1285 1285 1376 1420 1421 1597 1606 1628 1831
Centre of gravity (during operation)
X A,E mm 1056 1372 1372 1316 1324 1324 1562 1561 1543 1980
Y A,E mm 537 539 539 528 529 528 531 532 529 535
Weight distribution in % on the supports (during operation)
1 A,E % 31% 28% 28% 30% 30% 30% 19% 19% 20% 7%
2 A,E % 29% 27% 27% 28% 27% 27% 18% 18% 18% 7%
3 A,E % 20% 23% 23% 22% 22% 22% 18% 18% 17% 31%
4 A,E % 19% 22% 22% 20% 21% 21% 17% 17% 16% 29%
5 A,E % - - - - - - 15% 15% 15% 13%
6 A,E % - - - - - - 14% 14% 14% 12%
INTEGRATED HYDRONIC KIT: 09, I1, I2, I3, I4, K1, K2, K3, K4, W1, W2, W3, W4
Weights
Layout A,E type c.s. c.s. c.s. c.s. c.s. c.s. c.s. c.s. c.s. c.s.
Weight functioning A,E kg c.s. c.s. c.s. c.s. c.s. c.s. c.s. c.s. c.s. c.s.
Centre of gravity (during operation)
X A,E mm c.s. c.s. c.s. c.s. c.s. c.s. c.s. c.s. c.s. c.s.
Y A,E mm c.s. c.s. c.s. c.s. c.s. c.s. c.s. c.s. c.s. c.s.
Weight distribution in % on the supports (during operation)
1 A,E % c.s. c.s. c.s. c.s. c.s. c.s. c.s. c.s. c.s. c.s.
2 A,E % c.s. c.s. c.s.
c.s. c.s. c.s. c.s. c.s. c.s. c.s.
3 A,E % c.s. c.s. c.s. c.s. c.s. c.s. c.s. c.s. c.s. c.s.
4 A,E % c.s. c.s. c.s. c.s. c.s. c.s. c.s. c.s. c.s. c.s.
5 A,E % c.s. c.s. c.s. c.s. c.s. c.s. c.s. c.s. c.s. c.s.
6 A,E % c.s. c.s. c.s. c.s. c.s. c.s. c.s. c.s. c.s. c.s.
INTEGRATED HYDRONIC KIT: P1, P3
Weights
Layout A,E type 1 2 2 2 2 2 3 3 3 4
Weight functioning A,E kg 860 938 938 1029 1073 1074 1140 1149 1171 1377
Centre of gravity (during operation)
X A,E mm 1080 1252 1252 1187 1204 1203 1460 1459 1437 1753
Y A,E mm 552 554 554 537 538 538 544 544 540 547
Weight distribution in % on the supports (during operation)
1 A,E % 29% 30% 30% 32% 32% 32% 28% 28% 29% 12%
2 A,E % 29% 30% 30% 31% 31% 31% 27% 27% 28% 12%
3 A,E % 21% 20% 20% 19% 19% 19% 3% 3% 3% 27%
4 A,E % 21% 20% 20% 18% 18% 18% 3% 3% 3% 27%
5 A,E % - - - - - - 19% 19% 19% 11%
6 A,E % - - - - - - 19% 19% 19% 11%
INTEGRATED HYDRONIC KIT: P2, P4
Weights
Layout A,E type 1 2 2 2 2 2 3 3 3 4
Weight functioning A,E kg 912 997 997 1088 1133 1134 1188 1197 1219 1425
Centre of gravity (during operation)
X A,E mm 1133 1297 1297 1232 1246 1245 1506 1505 1483 1802
Y A,E mm 549 551 551 535 536 536 542 542 539 545
Weight distribution in % on the supports (during operation)
1 A,E % 28% 29% 29% 31% 31% 31% 27% 27% 28% 12%
2 A,E % 28% 29% 29% 30% 30% 30% 26% 26% 27% 12%
3 A,E % 22% 21% 21% 20% 20% 20% 3% 3% 3% 27%
4 A,E % 22% 21% 21% 19% 19% 19% 3% 3% 3% 26%
5 A,E % - - - - - - 21% 21% 21% 12%
6 A,E % - - - - - - 20% 20% 20% 12%
c.s. = contact the factory
