MODEL
EMPTY
PERCENTAGE WEIGHT DISTRIBUTION ON
SUPPORTS (%)
AVX
Weight
CENTRE OF GRAVITY
Xg Yg A B C D
NXW0800 ° 989 421 1224 23% 26% 24% 27% 310
NXW0800 ° + 1 pump 1105 415 1244 28% 30% 20% 21%
651
NXW0800 ° + 2 pumps 1165 412 1297 28% 29% 21% 22%
NXW0800 ° + 3 pumps 1226 410 1345 27% 28% 22% 23%
NXW0800 ° + 4 pumps 1286 407 1389 26% 27% 23% 24%
NXW0900 ° 1180 427 1217 23% 27% 23% 27% 314
NXW0900 ° + 1 pump 1296 421 1336 29% 32% 19% 21%
665
NXW0900 ° + 2 pumps 1356 419 1391 28% 31% 20% 21%
NXW0900 ° + 3 pumps 1417 416 1441 28% 30% 20% 22%
NXW0900 ° + 4 pumps 1477 414 1487 27% 29% 21% 23%
NXW1000 ° 1417 428 1309 21% 25% 25% 29% 316
NXW1000 ° + 1 pump 1558 422 1421 27% 31% 20% 22%
653
NXW1000 ° + 2 pumps 1644 419 1481 27% 30% 21% 23%
NXW1000 ° + 3 pumps 1730 416 1535 26% 29% 22% 23%
NXW1000 ° + 4 pumps 1765 415 1555 26% 28% 22% 24%
NXW1250 ° 1461 426 1304 22% 25% 25% 29% 316
NXW1250 ° + 1 pump 1602 421 1414 28% 31% 20% 22% 654
NXW1250 ° + 2 pumps 1688 418 1472 27% 30% 21% 23%
NXW1250 ° + 3 pumps 1774 415 1525 27% 29% 22% 23%
NXW1250 ° + 4 pumps 1809 414 1546 26% 28% 22% 24%
NXW1400 ° 1539 425 1326 21% 24% 26% 29% 315
NXW1400 ° + 1 pump 1680 420 1429 28% 30% 20% 22%
654
NXW1400 ° + 2 pumps 1765 417 1485 27% 29% 21% 23%
NXW1400 ° + 3 pumps 1851 415 1535 26% 28% 22% 23%
NXW1400 ° + 4 pumps 1886 414 1554 26% 28% 22% 24%
21.2. PERCENTAGE DISTRIBUTION OF WEIGHTS ON SUPPORTS
(VERSION ° - SIZES FROM 0800 TO 1400)
Note
- The number of pumps refers to the quantity physically present on the machine.
- The weight difference between the types of configurator pumps (low head and high head)
is negligible.
41
