MODEL
EMPTY
PERCENTAGE WEIGHT DISTRIBUTION ON
SUPPORTS (%)
AVX
Weight
CENTRE OF GRAVITY
Xg Yg A B C D
NXW0500L ° 750 399 834 28% 27% 23% 22% 309
NXW0500L ° + 1 pump 932 392 895 34% 33% 17% 16% 321
NXW0500L ° + 2 pumps 979 391 948 33% 32% 18% 17%
311
NXW0500L ° + 3 pumps 1026 389 996 32% 31% 19% 18%
NXW0500L ° + 4 pumps 1074 388 1183 29% 27% 23% 21% 312
NXW0550L ° 755 399 832 28% 27% 23% 22% 309
NXW0550L ° + 1 pump 936 392 892 34% 33% 17% 16% 321
NXW0550L ° + 2 pumps 983 391 946 33% 32% 18% 17%
311
NXW0550L ° + 3 pumps 1031 390 994 32% 31% 19% 18%
NXW0550L ° + 4 pumps 1078 389 1180 29% 27% 22% 21% 312
NXW0600L ° 854 404 888 26% 26% 24% 24% 310
NXW0600L ° + 1 pump 1036 397 933 33% 32% 17% 17%
311
NXW0600L ° + 2 pumps 1083 395 979 32% 32% 18% 18%
NXW0600L ° + 3 pumps 1130 394 1022 32% 31% 19% 19% 312
NXW0600L ° + 4 pumps 1178 393 1191 28% 27% 22% 22%
NXW0650L ° 863 405 887 26% 26% 24% 24% 303
NXW0650L ° + 1 pump 1048 397 935 33% 32% 17% 17%
311
NXW0650L ° + 2 pumps 1098 396 984 32% 31% 18% 18%
NXW0650L ° + 3 pumps 1149 394 1029 31% 31% 19% 19% 312
NXW0650L ° + 4 pumps 1200 393 1197 28% 27% 23% 22% 310
NXW0700L ° 900 407 901 25% 26% 24% 25% 303
NXW0700L ° + 1 pump 1084 400 1085 30% 30% 20% 20%
651
NXW0700L ° + 2 pumps 1135 398 1126 29% 29% 21% 21%
NXW0700L ° + 3 pumps 1186 396 1164 29% 28% 22% 21%
NXW0700L ° + 4 pumps 1236 395 1198 28% 27% 22% 22%
NXW0750L ° 1054 410 1087 24% 25% 25% 26% 310
NXW0750L ° + 1 pump 1249 403 1271 29% 29% 21% 21%
651
NXW0750L ° + 2 pumps 1310 401 1318 28% 28% 22% 22%
NXW0750L ° + 3 pumps 1370 399 1360 27% 27% 23% 23%
NXW0750L ° + 4 pumps 1411 398 1386 27% 27% 23% 23%
Note
- The number of pumps refers to the quantity physically present on the machine.
- The weight difference between the types of configurator pumps (low head and high
head / evaporator and condenser side) is negligible.
21.5. PERCENTAGE DISTRIBUTION OF WEIGHTS ON SUPPORTS
(VERSION L - SIZES FROM 0800 TO 1400)
44
INXWPY. 1004. 4438805_00
