MODEL
EMPTY
PERCENTAGE WEIGHT DISTRIBUTION ON
SUPPORTS (%)
AVX
Weight
CENTRE OF GRAVITY
Xg Yg A B C D
NXW0500H H 628 401 849 27% 27% 23% 23% 319
NXW0500H H + 1 pump 730 396 923 33% 33% 17% 17%
320
NXW0500H H + 2 pumps 778 394 989 32% 31% 19% 18%
NXW0500H H + 3 pumps 825 392 1047 31% 30% 20% 19%
309
NXW0500H H + 4 pumps 872 390 1098 30% 29% 21% 20%
NXW0550H H 633 401 846 27% 27% 23% 23% 319
NXW0550H H + 1 pump 735 396 920 33% 33% 17% 17%
320
NXW0550H H + 2 pumps 782 394 985 32% 31% 19% 18%
NXW0550H H + 3 pumps 829 392 1043 31% 30% 20% 19%
309
NXW0550H H + 4 pumps 877 391 1095 30% 29% 21% 20%
NXW0600H H 734 406 911 25% 26% 24% 25% 301
NXW0600H H + 1 pump 836 401 968 32% 32% 18% 18% 320
NXW0600H H + 2 pumps 884 399 1023 31% 31% 19% 19%
309
NXW0600H H + 3 pumps 931 397 1073 30% 30% 20% 20%
NXW0600H H + 4 pumps 978 395 1118 30% 29% 21% 20% 312
NXW0650H H 743 407 910 25% 26% 24% 25% 301
NXW0650H H + 1 pump 848 401 970 32% 32% 18% 18%
309
NXW0650H H + 2 pumps 899 399 1028 31% 31% 19% 19%
NXW0650H H + 3 pumps 950 397 1080 30% 30% 20% 20% 311
NXW0650H H + 4 pumps 1000 396 1127 29% 29% 21% 21% 312
NXW0700H H 791 406 932 24% 25% 25% 26% 302
NXW0700H H + 1 pump 896 401 1048 31% 31% 19% 19% 309
NXW0700H H + 2 pumps 947 399 1099 30% 30% 20% 20% 311
NXW0700H H + 3 pumps 997 397 1145 29% 29% 21% 21% 312
NXW0700H H + 4 pumps 1048 395 1186 28% 28% 22% 22%
NXW0750H H 948 410 1103 24% 25% 25% 26% 310
NXW0750H H + 1 pump 1064 405 1223 27% 28% 22% 23%
651
NXW0750H H + 2 pumps 1124 403 1279 26% 26% 24% 24%
NXW0750H H + 3 pumps 1185 401 1330 25% 25% 25% 25%
NXW0750H H + 4 pumps 1225 399 1361 27% 27% 23% 23%
Note
- The number of pumps refers to the quantity physically present on the machine.
- The weight difference between the types of configurator pumps (low head and high
head / evaporator and condenser side) is negligible.
21.3.
PERCENTAGE DISTRIBUTION OF WEIGHTS ON SUPPORTS
(VERSION H
- SIZES FROM 0500 TO 0750)
42
INXWPY. 1004. 4438805_00
