AERMEC NXW 0900 User Manual

MODEL
EMPTY
PERCENTAGE WEIGHT DISTRIBUTION ON
SUPPORTS (%)
AVX
Weight
CENTRE OF GRAVITY
Xg Yg A B C D
NXW0800L ° 1187 411 1226 24% 25% 25% 26% 314
NXW0800L ° + 1 pump 1357 405 1292 28% 29% 21% 22%
652
NXW0800L ° + 2 pumps 1417 403 1334 28% 28% 22% 22%
NXW0800L ° + 3 pumps 1478 402 1373 27% 27% 23% 23%
NXW0800L ° + 4 pumps 1538 400 1408 27% 27% 23% 23%
NXW0900L ° 1378 418 1220 24% 26% 24% 26% 314
NXW0900L ° + 1 pump 1585 411 1399 29% 30% 20% 21%
653
NXW0900L ° + 2 pumps 1646 409 1442 28% 29% 21% 22%
NXW0900L ° + 3 pumps 1706 407 1482 28% 29% 21% 22%
NXW0900L ° + 4 pumps 1767 406 1519 27% 28% 22% 23%
NXW1000L ° 1615 420 1300 22% 24% 26% 28% 315
NXW1000L ° + 1 pump 1847 413 1462 28% 29% 21% 22%
654
NXW1000L ° + 2 pumps 1933 411 1511 27% 29% 22% 23%
NXW1000L ° + 3 pumps 2019 409 1556 27% 28% 22% 23%
NXW1000L ° + 4 pumps 2054 408 1573 26% 27% 23% 24%
NXW1250L ° 1659 419 1296 22% 24% 26% 28% 315
NXW1250L ° + 1 pump 1891 412 1455 28% 29% 21% 22%
659
NXW1250L ° + 2 pumps 1977 410 1503 27% 29% 22% 23%
NXW1250L ° + 3 pumps 2063 408 1547 27% 28% 22% 23%
NXW1250L ° + 4 pumps 2098 407 1564 27% 27% 23% 23%
NXW1400L ° 1737 418 1316 22% 24% 26% 28% 317
NXW1400L ° + 1 pump 1969 411 1466 28% 29% 21% 22%
659
NXW1400L ° + 2 pumps 2055 409 1512 27% 28% 22% 23%
NXW1400L ° + 3 pumps 2140 407 1555 27% 28% 22% 23%
NXW1400L ° + 4 pumps 2176 407 1571 26% 27% 23% 24%
Note
- The number of pumps refers to the quantity physically present on the machine.
- The weight difference between the types of configurator pumps (low head and high
head / evaporator and condenser side) is negligible.
21.6. PERCENTAGE DISTRIBUTION OF WEIGHTS ON SUPPORTS
(VERSION L - SIZES FROM 0800 TO 1400)
45
INXWPY. 1004. 4438805_00
