MODEL
EMPTY
PERCENTAGE WEIGHT DISTRIBUTION ON
SUPPORTS (%)
AVX
Weight
CENTRE OF GRAVITY
Xg Yg A B C D
NXW0500HL H 801 393 847 28% 27% 23% 22% 309
NXW0500HL H + 1 pump 982 387 902 34% 32% 17% 16%
311
NXW0500HL H + 2 pumps 1030 386 952 33% 31% 18% 17%
NXW0500HL H + 3 pumps 1077 385 998 33% 30% 19% 18%
312
NXW0500HL H + 4 pumps 1124 384 1041 32% 30% 20% 19%
NXW0550HL H 805 393 845 28% 27% 23% 22% 309
NXW0550HL H + 1 pump 987 388 900 34% 32% 17% 16%
311
NXW0550HL H + 2 pumps 1034 387 950 33% 31% 18% 17%
NXW0550HL H + 3 pumps 1081 386 996 33% 30% 19% 18%
312
NXW0550HL H + 4 pumps 1129 385 1038 32% 30% 20% 18%
NXW0600HL H 907 398 897 26% 26% 24% 24% 310
NXW0600HL H + 1 pump 1088 392 938 33% 32% 18% 17% 311
NXW0600HL H + 2 pumps 1135 391 983 33% 31% 19% 18%
312NXW0600HL H + 3 pumps 1183 390 1023 32% 30% 19% 18%
NXW0600HL H + 4 pumps 1230 389 1061 31% 30% 20% 19%
NXW0650HL H 915 399 897 26% 26% 24% 24% 303
NXW0650HL H + 1 pump 1100 393 941 33% 32% 18% 17% 311
NXW0650HL H + 2 pumps 1151 391 987 32% 31% 19% 18%
313NXW0650HL H + 3 pumps 1201 390 1030 32% 30% 20% 19%
NXW0650HL H + 4 pumps 1252 389 1069 31% 29% 20% 19%
NXW0700HL H 963 398 916 25% 25% 25% 25% 304
NXW0700HL H + 1 pump 1148 393 1088 30% 29% 21% 20%
651
NXW0700HL H + 2 pumps 1199 392 1126 30% 29% 21% 20%
NXW0700HL H + 3 pumps 1249 390 1162 29% 28% 22% 21%
NXW0700HL H + 4 pumps 1300 389 1194 29% 27% 23% 22%
NXW0750HL H 1121 403 1105 24% 24% 26% 26% 314
NXW0750HL H + 1 pump 1316 397 1277 27% 26% 24% 23%
652
NXW0750HL H + 2 pumps 1376 395 1321 26% 25% 25% 24%
NXW0750HL H + 3 pumps 1437 394 1361 25% 24% 26% 25%
NXW0750HL H + 4 pumps 1477 393 1386 27% 27% 23% 23%
Note
- The number of pumps refers to the quantity physically present on the machine.
- The weight difference between the types of configurator pumps (low head and high
head / evaporator and condenser side) is negligible.
21.7. PERCENTAGE DISTRIBUTION OF WEIGHTS ON SUPPORTS
(VERSION HL - SIZES FROM 0500 TO 750)
46
INXWPY. 1004. 4438805_00
