10.8.  Plenum performances
Plenum performances with
Option “W”
PLS350W
PLSM350W
PLS650W
PLSM650W
 m
3
/h 350 650
Cooling
Total cooling capacity W 1730 3470
Sensible cooling capacity W 1300 2480
Sensible/Total heat rao W/W 0,751 0,715
Water ow rate L/h 297 597
Water side pressure drop kPa 10,8 32
Water inlet temperature °C 7 7
Water temperature rise °C 5 5
Air inlet temperature °C, db 27 27
Air inlet temperature °C, wb 19 19

Heang capacity W 1900 3500
Water ow rate l/h 331 610
Water side pressure drop kPa 6,5 24,4
Water inlet temperature °C 45 45
Water temperature drop °C 5 5
Air inlet temperature °C 20 20
Plenum performances with re-heat electric coil
Option “E”
PLS350E
PLSM350E
PLS650E
PLSM650E
Electric heater power input W 710 710
Electrical power supply V ~ Hz 230 ~ 50 230 ~ 50
Plenum performances with germicidal UV lamp
Option “L”
PLS350L
PLSM350L
PLS650L
PLSM650L
Power absorbed by the UV lamp W 10 10
Electrical power supply V ~ Hz 230 ~ 50 230 ~ 50
Losses of plenum load
with water battery (W)
with water battery and electrical resistance (WE)
with water battery and UV light (WL)
with water battery and electrical resistance and UV lamp
(WLE)
with with electric resistance (E)
with UV lamp (L)
with electric resistance and UV lamp (LE)
PLS350W
PLS350WE
PLS350WL
PLS350WLE
PLSM350W
PLSM350WE
PLSM350WL
PLSM350WLE
PLS650W
PLS650WE
PLS650WL
PLS650WLE
PLSM650W
PLSM650WE
PLSM650WL
PLSM650WLE
PLS350E
PLS350L
PLS350LE
PLSM350E
PLSM350L
PLSM350LE
PLS650E
PLS650L
PLS650LE
PLSM650E
PLSM650L
PLSM650LE
m
3
/h Pa Pa Pa Pa
50 2 2 1 1
100 6 2 3 1
150 10 4 5 2
200 16 8 8 4
250 22 10 11 5
300 30 14 15 7
350 40 18 20 9
400 - 22 - 11
450 - 28 - 14
500 - 32 - 16
550 - 38 - 19
600 - 44 - 22
650 - 50 - 25
