25
IVES0LJ 1707 - 5880761_01
The fan coils of the VES series have been designed to adjust the static pressure provided by the fan according to the duct pressure
drops, by selecting an appropriate speed.
The chart shows the useful static pressure of the machines with an enhanced multi-speed motor according to the fan air flow rate and
speed (V1...V6).
VES 040
FLOW STATIC PRESSURE
Air flow rate [m
3
/h]
Useful static pressure [Pa]
VES 030
Air flow rate [m
3
/h]
Useful static pressure [Pa]
