34
IVES0LJ 1707 - 5880761_01
ACCESSORIES
VES
030 040 130 140 230 240 330 340
Control panel and special accessories
KTLP • • • • • • • •
PX-PX2-PX2C6 (1) • • • • • • • •
PXAE • • • • • • • •
PXAR • • • • • • • •
TPF • • • • • • • •
WMT05-06-10 • • • • • • • •
FMT10 • • • • • • • •
FMT21 • • • • • • • •
SWA Combined with FMT21
SW3 Combined with PXAE or PXAR
SIT3 Combined with FMT21 or PXAE or PXAR or PX2 or PX or PX2C6 WMT05*-06-10
SIT5 Combined with FMT21 or PXAE or PXAR
VMF system
VMF-E0 • • • • • • • •
VMF-E1 • • • • • • • •
VMF-E4 • • • • • • • •
VMF-E5 • • • • • • • •
VMF-SW • • • • • • • •
VMF-SW1 • • • • • • • •
Additional coil (heating only)
BV030 •
BV130 •
BV230 •
BV162 •
Water valves
Valve kit for 4-pipe systems with standard coil
VCF3X4L-R • • • • • • • •
3-way valve kit
VCF43/4324 (2) • • • • • •
VCF43S/4324S (2) • •
ACCESSORIES
a range of dedicated wall-mounted controls is available
but it is essential to choose between these panels for simple
and complete tuning, for more details please refer to the
dedicated sheet.
• SW3: Water temperature probe that allows season
automatic change-over at the electronic thermostats
with water side change-over.
• SWA: External probe accessory SWA (length L = 6m). It
detects the temperature of the room air if connected
to the connector (A) of the FMT21 panel. The room
air temperature probe, incorporated in the panel, is
automatically disabled. It detects the temperature of
the water in the system for ventilation consent if con-
nected to the connector (W) of the FMT21 panel. Two
SWA probes can be connected simultaneously to the
FMT21 panel.
Thermostat Interface Boards. They allow the
set-up of a fan coil network (max. 10) controlled by a
centralised panel (switch or thermostat).
SIT3: controls the 3 fan speeds and must be installed
on each network fan coil; receives commands from the
switch or from the SIT5 board.
SIT5: controls the 3 fan speeds and up to 2 valves (four-
pipe systems); transmits the thermostat commands to
the fan coil network.
thermostat accessory to be secured to the
side of the fan coil, fitted as standard with an air probe
and a water probe, controls systems with 2 pipes, 4
pipes, 2 pipes + Plasmacluster, 2 pipes + UV lamps, 2
pipes + Heating element Equipped with an external
contact to be used as a remote ON-OFF at low volt-
age. By means of 2-wire serial communication, this
thermostat allows for the creation of a single fan coil
area (1 master + maximum 5 slaves). The thermostat is
protected by a fuse
The wall recessed panel allows you to control
the functions of a complete hydronic system via a
capacitive touch keyboard.
• BV:
• VCF_X4: Kit of valves for systems with 4 pipes and
fan coils with one 2-connection coil. Kit made of
special motorised 3-way valves with isolating shell, fit-
tings and isolated copper pipes. _X4L Version for left
connection fan coils. _X4R Version for right connection
fan coils. 230V~50Hz power supply
• VCF: Kit of 3-way motorised valves with insulating
shell, insulated copper fittings and pipes. For standard
or larger main coil and for heating-only coil. Versions
with 230V and 24V~50Hz power supply.
For standard or larger main coil and for
heating-only coil. Versions with 230V and 24V~50Hz
power supply.
• VJP/VJP_M:
The valve can guarantee a
constant water flow in the terminal within its operating
range. Available with 230V and 24V ~ 50Hz power sup-
ply.
The VJP is controlled by an on-off logic with compat-
ible control panels (accessories)
VJP_M is controlled by a modulating logic with pan-
els not supplied by Aermec
The flow rate of the project is crucial to refine the
selection of the valves shown in the compatibility
table.
• AMP: Kit for wall/ceiling mounted installation.
Auxiliary condensate drip tray.
• DSC4: Condensate draining device when level differ-
ences must be exceeded.
• SE: External air damper with manual control
Accessories for ducted installation:
• RDA_V: Straight intake fitting with rectangular flange.
• RDAC_V: Straight intake fitting with circular flanges.
• RPA_V: Intake plenum with rectangular flange.
• RDMC_V: Straight flow fitting with circular flanges.
Internal insulation.
• PA_V: Intake plenum with circular flanges. Plastic
flanges.
• RPM_V: Flow plenum with rectangular flange. Internal
insulation.
• PM_V: Flow plenum with circular flanges. Internal insu-
lation. Plastic flanges.
• KFV10: Circular flange kit for intake/flow plenum.
Flow and intake grid:
• GA: Intake grid with fixed louvers.
• GAF: Intake grid with fixed louvers with filter.
• GM: Flow grid with adjustable louvers.
For more details on the control panels and VMF system refer
to the special data sheets
