AERMEC VES Technical Manual

32
5880751_01
VES_I
030 040 130 140 230 240 330 340
Auxiliary condensate drip tray
BC4 • • • • • • • •
BC6 • • • • • • • •
BC9 • • • • • • • •
Grille
GA22 • •
GA32 • •
GA42 • •
GA62 • •
GAF22 • •
GAF32 • •
GAF42 • •
GAF62 • •
GM22 • •
GM32 • •
GM42 • •
GM62 • •
SE20X (3) • •
SE30X (3) • •
SE40X (3) • •
SE80X (3) • •
Plenum for duct installation
RDA000V • •
RDA100V • •
RDA200V • •
RDA300V • •
RPA000V (4) • •
RPA100V (4) • •
RPA200V (4) • •
RPA300V (4) • •
RDAC000V • •
RDAC100V • •
RDAC200V • •
RDAC300V • •
PA000V (4) • •
PA100V (4) • •
PA200V (4) • •
PA300V (4) • •
PM000V (4) • •
PM100V (4) • •
PM200V (4) • •
PM300V (4) • •
RPM000V (4) • •
RPM100V (4) • •
RPM200V (4) • •
RPM300V (4) • •
RDMC000V • •
RDMC100V • •
RDMC200V • •
RDMC300V • •
KFV10 • • • • • • • •
For more details on the control panels and VMF system refer to the dedicated sheet.
(1) VCF4324-VCFD324-VCF4524-VCZD424-VJP060M are 24V
(2) DSC4 It's not available with AMP - BC -VMF system.
(3) The accessory SE require pairing with ZX
(4) All the Plenums ( RPA_V; PA_V; RPM_V; PM_V ) have a circular push-outs (Ø=150mm ) on both sides, which can be removed, All the can have intake/discharge either
straight or downwards (straight or downwards with reference to horizontal installation).
