AERMEC WRC50 - Operation Notices; Display; LCD of the Wired Controller

5
2 OPERATION NOTICES
1. The power supply for all indoor units must be unied.
2. Never install the wired controller in the moist circumstance or expose it directly under the sunlight.
3. Never beat, throw, and frequently disassemble the wired controller and the wireless remote controller.
4. Never operate the wired controller and the wireless remote controller with wet hands.
5. This product is applicable to LPG unit whose outdoor unit and indoor unit communicate with each other by live line and neutral line.
6. When two wired controllers control one (or more) indoor unit(s), the address of wired controller should be dierent.
3 DISPLAY
Fig. 3.1: Outside View of the Wired Controller
2
3 D
3.1 LCD OF THE WIRED CONTROLLER
Fig. 3.2: LCD graphics of wired controller
2
3 D
1 2 3 4 5 6 7 8 9 10
24
25
27
29
31
26
23 22 21 20 19 18 17 16 15
14
13
28
30
32
33
12
11
