AES global CellCOM PRIME - Imperial Model Component Breakdown

P a g e | 15
Imperial Version
Microphone (10)
Optional
illuminated
keypad.
(14/15)
Security screw
access
Powder
coated hood
Waterproof Mylar
1.5W speaker (
9
)
Illuminated IP67
push button (5/6)
Optional PROX
reader (11)
GSM Assembly
(2)
Optional Keypad (14/15) &
PROX module (11)
Mounting holes
Cable entry hole
Call button (5/6)
RVT
RVT
RVT
RVT
RVT
RVT
RVT
RVT
101101
Relay 1
Relay 2
8.000
USB
Prox Coil
Reader (11)
