AES global CellCOM PRIME - Multi-button Imperial Model Details

P a g e | 16
Imperial Version (multi-button)
Microphone (10)
Optional
Illuminated
Keypad. (14/15)
Security Screw
Access
DDA
LED’s
Waterproof Mylar
1.5W Speaker (9)
Illuminated IP67
Push Buttons (8)
Optional PROX
Reader (11)
Illuminated
Nameplate
Windows
Nameplate Illumination
and multibutton PCB (3)
GSM
Assembly (2)
Button 1 Button 2
Button 3
Button 4
C
C
C
C
+
-
= COMMON = COMMON
Optional Keypad (14/15)
& PROX Module (11)
Mounting Holes
Cable Entry Hole
Call Buttons
(8)
RVT
RVT
RVT
RVT
RVT
RVT
RVT
RVT
101101
Relay 1
Relay 2
8.000
USB
Prox Coil
Reader (11)
