AES global CellCOM PRIME - Auxiliary Device Relay Setup Configuration

P a g e | 36
Relay 3
Relay 4
Relay 5
5
Relay 6
Relay 7
Relay 8
ON
DIP
1 2 3 4
ON
DIP
1 2 3 4
ON
DIP
1 2 3 4
ON
DIP
1 2 3 4
ON
DIP
1 2 3 4
ON
DIP
1 2 3 4
Dip switch configuration for
relays 3 to 8 on auxiliary
devices.
1 2 3 4
ON
DIP
24V 1 2 3
NC COM N O PTE
24V 1 2 3
1 2 3 4
ON
DI P
SLA VE IN
SLA VE OUT
1 2 3
1 2 3
IN
+ 24V -
OUT
+ 24V -
IN
1 2 3
OUT
1 2 3
COIL
The sounder boards dip switches
set the relay number for the
auxiliary unit it is in.
The dip switch of the prox must
match the dip switch configuration
of the auxiliary it wants to trigger
*#91#RelayNumber#
(Relay Number = 3-8)
A keypad does not have dip switches.
To assign the relay number use the
keypad keys as follows.
4
5 6
1 2 3
7 8
9
*
0 #
Auxiliary Device Relay Setup
