Figure 3-3: Verify Test Jumpers.

New adapter cap

(if necessary)

Transmit jumper

Do NOT disturb

this connection

Adapter

Receive jumper

Mandrel wrap

16 If the insertion loss is acceptable, disconnect the transmit and receive jumpers at the

adapter.

17 Move the CSM1 and CSS1 to opposite ends of the link to be tested.
