20 Operation
4510003 Rev B
Temperature Control Module
The SDC15 (Temperature Control) controls the chamber temperature in the heat zone.
Heating elements are inside the top of the tunnel and run the length of the tunnel.
After a temperature setpoint has been selected, run some product and observe the
results. To adjust the temperature, set the control to the new desired temperature.
Always wait for tunnel heat to stabilize before making changes.
Heating
Elements
Temperature
Control
