The control has an alarm output which is factory set to process high and process low
temperatures. The heat turns off if the chamber temperature exceeds 425 °F or falls
below the low process temperature setting.
Current Transformer Input
Refer to the SDC Temperature Control Manual for more information.
pv
sp
mode
para
SDC15
TEMPERATURE
CONTROL
ot2
ot1ev3ev2ev1manrdy
Upper Display
Lower Display
Para Key
Digital Shift/Numeric Key
