ES-200A Recommended Replacement Parts List
Item
Number
Stock
Number Description Manufacturing Number Qty
000021 4500591 ELEMENT, HEATER 36" 2KW/115V ELEM754 3.000
000323 4500784 FUSE UL CLASS CC MID. TD, 600 VAC, 5 AMPS, TYPES: LP-CC, ATD 2.000
000322 4501960 FUSE, TYPE J 30A LPJ35SP 3.000
000358 4501403 RTD 100 OHM 8" LONG 1.000
000331 4501375 RELAY; SSR; ZERO-SW; CUR-RTG 50A; CTRL-V 3-32DC; VOL-RTG 48 1.000
000359 4501098 MOTOR, 3000RPM 115/230V 2.000
ES-200A V6 (480V) Parts List
Part Number Description Specification Qty
5AA01C10T6DTD0100
TEMPERATURE
CONTROLLER
C15TV0TD0100 24V
AC/DC SSR
1
5AA04C12D10A7 MAGNETIC CONTACTOR C-12D10A7 AC24V 4A 1
5AA04C25D10A7 MAGNETIC CONTACTOR C-25D10A7 AC24V 4A 1
5AA07BMY2CSLAC24 RELAY
BMY5-2C-SL-AC24V
(MY2N)
1
5AA09H3CRA8 TIMER
H3CR-A8 AC24-48/DC12-
48V
1
5AA1105VX2/05A026CE TRANSFORMERS CE 480/220V 5A.26V 5A 1
AA31APR3S6 PHASE RELAY APR-3S 480V 1
AA71NTH04 OVER-LOAD RELAY NTH-04 2
AA71NTH1.05 OVER-LOAD RELAY NTH-1.05 0.7-1.05A 2
AA72CA1D22 EXTRA CONTACT CA1-D22 2A2B 4
AA915MX1 THERMOCOUPLE 5M 1
AB02MSO12DA7N2.5 ELECTROMAGNETIC SWITCH
MSO12DA7N2.5A 1.8-
2.5A
2
AB033PCS20 CIRCUIT BREAKER 3P20A CE (604836) 1
AB07HL5030 LIMIT SWITCH HL-5030 (TZ-8108) 2
AB16ZHC316 POWER SWITCH FCH-ZH-C316 3P16A 1
