33 Dimensions
4510003 Rev B
Part Number Description Specification Qty
AB31ABF221B2R PUSH BUTTON FHD-NPB22-F01R 220V 1
AB33SHAF2212B2R
PUSH BUTTON FOR
EMERGENCY STOP
FHD-NPB22-R02 2B220V 1
AB61AC222P1A2B SELECTOR SWITCH FHD-NSS-22-S210-BK 1
AB66ABLFS221A8BL ILLUMINATION BUTTON
FHD-NLB22-F10BL-A
1A24
2
AB66ABLFS221A8G ILLUMINATION BUTTON
FHD-NLB22-F10G-A
1A24V
1
AB66ABLFS221B8R ILLUMINATION BUTTON
FHD-NLB22-F01R-A
1B24V
1
5AC03ACTCTFB101L FUSE BLOCK
ACT-CT-FB101L 10X38
1P
11
5AC04FF1038X02 FUSE ACT-CT-FWC16 10X38 2A 2
5AC04FF1038X04 FUSE ACT-CT-FWC16 10X38 4A 2
5AC04FF1038X06 FUSE ACT-CT-FWC16 10X38 6A 3
5AC04FF1038X10 FUSE
ACT-CT-FWC16 10X38
10A
1
5AC04FF1038X16 FUSE
ACT-CT-FWC16 10X38
16A
3
5AC07TBC48P20A TERMINAL BLOCK TBC-48P20A 1
5AC11PF083A REALY SOCKET PF083AE 2
5AC11PYF08A REALY SOCKET PYF08A (E) 1
5AC14JK4C25A3B75 SOLID-STATE RELAY
JK4C25A3B75 SSR 3
PHASE 480V
1
5AC207P COPPER-GROUND-BAR 7P 1
5AE02AE2224G LIGHT
NLD22 24V GREEN
AC/DC
1
5AE02AE2224W LIGHT NLD22 24V WHITE AC/DC 1
5AF01A51340XE20 HEATER
5/8 PHASE
X1340M/MX277VX2KW
6
5AG1312X12X2 COOLING FAN WITH COVER
12X12CN 220V
ACIUF120B2+FG120
3
