2.1.5 VARYING DISTANCE OF APPLICATION
It is also possible to alter the distance the material is distributed.
Moving distribution bolt (A) from its standard factory setting, as shown in the image above,
will increase or decrease the distance the product will be thrown from the dispenser onto
the cubicle.
Moving the distribution
bolt in this direction will
increase the distance the
product is thrown.
A
Moving the distribution
bolt in this direction will
decrease the distance the
product is thrown.
