AG Mini Operation Manual
AR / 25.07.23 / Version 1 15
3 SPECIFICATIONS
3.1 ASSEMBLY OF AG MINI
Practice workshop safety at all times!
CAUTION
Disconnect battery before assembly of AG Mini.
1) Ensure the AG Mini is placed on the ground in a stable condition.
2) Ensure all guards are fitted correctly before use.
Place the wheel onto the base frame of the machine and
then secure by placing the washer and external Circlip in
the order shown.
Finally fit the wheel cap to ensure the bearings are kept
free from foreign materials.
Insert handlebar connecting rods ensuring that the solid
end goes towards the bass of the bin.
Fit the handle to the main body and fasten using the nuts
and bolts provided.
