Ensure a clearance gap of 3 mm
between the distributor arm and
the base of the machine indicated
by the arrow marked A.
Also ensure there is a gap of 5
mm between the distributor arm
and the top plate indicated by the
arrow marked B.
Ensure that the distribution
flexible arms are connected on
the left-hand side of the metal
frame of the distribution arms.
