AG Mini Operation Manual
AR / 25.07.23 / Version 1 17
3.2.1 CHARGING THE AG MINI
Read the charger manual provided in the charger box.
1) Ensure the switch is in position 1.
2) The AG Mini will require a complete
charge before use. Plug the male jack plug
into the female charger port.
3) The green light on the charger should
now illuminate for 5 seconds before
switching to a solid red light. The battery is
now charging.
4) When the green light illuminates, the
battery is fully charged and will continue to
“float charge”.
5) The AG Mini can be left on float charge
continuously.
• Only charge when switch is in position 1.
• Never charge the AG Mini with any other charger than the unit supplied.
• Never charge in the rain or wet conditions.
• Never leave the battery flat, always charge the battery after use.
• No damage will occur if left on “float charge” i.e. green light.
• Damage may occur to battery if it is left flat.
