AG MINI - Motor Removal

AG Mini Operation Manual
AR / 25.07.23 / Version 1 23
5.5 MOTOR REMOVAL
To remove the flicker vane, you need to first remove
the bin.
Then taking a punch and hammer you need to
remove the roll pin.
Once the roll pin is removed the vane will pull off.
For removal of the gear box, you need to remove
the three 8 mm nuts and bolts.
