AGA DC3 User Manual

25
Fig. 12.1
DESN 517427
DESN 516859
4.5 mm SCREW
HEAD DEPTH
DESN 516276
11mm height
differential
4.5 mm gap
Plinth base
Hotcupboard
Plinth base
FOR AGA TC5/DC5 + MODULE ONLY
DESN 516852
FOR AGA TC3/
DC3 + MODULE
ONLY
DESN 516858
FOR AGA TC5/DC5 +
MODULE ONLY
DESN 516276
Fig. 12.2
FOR AGA TC3/DC3 + MODULE ONLY
11mm height
differential
Plinth base
+1
-0
Fig. 12.3
Fig. 12.4
Fig. 12.5
Fig. 12.6
