34
Read all instructions before installing or using this appliance.
Installation Instructions
Save these instructions for future reference.
Fit the leveling tool on the rectangular adjuster
as shown below.
LOWER THE FRONT ROLLER by doing 14
complete (360°) turns clockwise. (This means
turning and removing the leveling tool 56 times).
Now LOWER THE TWO REAR ROLLERS.
First fit the leveling tool on the hexagonal
adjusting nut as shown below.
Make 10 complete (360°) turns clockwise. (This
means turning and removing the leveling tool 20
times).
Make sure you lower BOTH REAR ROLLERS.
There are two adjusting nuts, one for each
roller, at both the front bottom corners of the
range.
Note the rollers are only intended to aid
installation - the range should not be
moved once it is installed.
Push the range close to its final position, leaving
just enough space to get behind it.
Do not refit the storage drawer yet
IMPORTANT!
Remove all tape and packaging. Make sure the
burners are properly seated and level. Take the
accessory pack out of the oven. Check to be
sure that no range parts have come loose
during shipping.
Checking the parts
Check that the range has the following parts.
4 grates
Broiler pan and trivet
Leveling tool
