AGA Mercury - Fitting the Flue, Flue Vent and Side Panels

24
INSTALLATION
Check the appliance is electrically safe when you have nished.
Checking the Parts:
Flue Flue Vent
Fan Assembly Control knobs x 9
Fitting the Knobs
1. Gently push-t the control knobs onto the spindles.
Fitting the Flue
1. Remove the four screws from the broiler ue opening
(Fig. 9.1).
2. Present the removable ue up to broiler ue opening.
Make sure that the bottom ange of the removable ue
ts inside the xed ue, secure in place with the four
screws (Fig. 9.1).
Fitting the Flue Vent
1. Loosen the three nuts and bolts in the back of the
hotplate (Fig. 9.2).
2. Fit the ue vent over the bolts and slide down (Fig. 9.2).
Tighten the nuts to secure.
9. Fitting the Flue, Flue Vent and Side Panels
Fig. 9.1
Fig. 9.2
Flue
