Fitting the Interlocking Grates
Please note that the Continuous Grates supports are handed,
and may prevent the centre pan supports from tting
correctly. There is a small indent in the rear of each of the
outer supports. This indent should be towards the outer edge
of the range (Fig. 15.1).
Cooktop Check
Refer to Section 2, page 5 and check operation of each
burner in turn. Be sure to use pans of the correct size and
material.
Broiler Check
Refer to Section 2, page 7 and check operation of the
broiler and that it heats up*.
Oven Check
Refer to Section 2, page 9 and check the operation of
both ovens*. Check that the oven fans operate and the ovens
heat up.
* The cooling fan, located at the rear right hand side of the
cooktop, should operate with this function.
Customer Care
Installer: Please complete your details in this guide, inform
the user how to operate the range and hand over the
instructions.
15. Final Fitting
Fig. 15.1
