Fitting the Front Mounting
Brackets
1. Open the right-hand oven door and pull the drawer out
to its furthest point.
2. Push the ends of the plastic clips (Fig. 9.13 and Fig.
9.14) to release the catches holding the drawer to the
side runners. At the same time pull the drawer forward
and away from the side runners.
n
For safety’s sake make sure the drawer runners are
out of the way.
3. On the front of the range base there are two mounting
plates. Remove the three xing screws from each plate
(Fig. 9.15).
4. Fit the left and right-hand front mounting brackets
as shown in (Fig. 9.15 and Fig. 9.16). DO NOT over
tighten the mounting screws at this stage.
Fig. 9.13
Fig. 9.14
Fig. 9.15
Fig. 9.16
