INSTALLATION

Check the appliance is electrically safe when you have nished.

Side panel bracket

Flue Vent

Side Panel

Nylon Retaining

washer

Connect tab into

side bracket

Gasket

Removing the Side Panels

1. Loosen one screw in the vent (Fig. 10.5).

2. Push forward the side panel so that it moves away from

the ue vent and the retaining washer (Fig. 10.6).

3. Inside the top of the side panel top are two tabs. Move

the side panel up and away from the range (Fig. 10.7).

Fig. 10.5

Fig. 10.6

Fig. 10.7
