DX-D 100 Mobile X-ray Unit
User Manual
36
0188K EN 20201116
Quantitative Information
Loading Factors Parameter Selection
Filtration
Measured Doses
Patient
examination
(orientative)
kVp
mA
Time (s)
mAs
Focal Spot
Selection
SID
Source--Image Distance
(cm)
Collimator blades
opening
cm
Grid
HVL (mm Al)
measured value
(min. value allowed)
Collimator
Output Dose
(μGy*m2)
Phantom
Input Dose Rate
(μGy/s)
Phantom
Input Dose
(μGy/mAs)
Phantom
Output Dose
(μGy/mAs)
CHEST AP 95 160 0.02 3.2 Small 120 35 x 43 No
3.9
(>3.4)
27.3 11210 70.4 0.19
NECK 85 100 0.02 2 Small 100 24 x 30 No
3.7
(>3)
12.7 8246 82.45 0.1
ABDOMEN AP 80 400 0.025 10 Large 100 35 x 43 No
3.5
(>2.9)
59.3 29950 75.87 0.15
HIP AP 75 400 0.04 16 Large 100 35 x 43 No
3.2
(>2.7)
82.5 26270 65.67 0.11
KNEE AP 65 200 0.025 5 Large 100 24 x 30 No
4.1
(>2.3)
9.6 8953 44.56 0.06
ANKLE AP 60 100 0.04 4 Small 100 24 x 30 No
3.8
(>2.1)
4 3973 39.73 0.05
FOOT AP 60 100 0.032 3.2 Small 100 24 x 30 No
3.8
(>2.1)
4.5 3204 32.2 0.094
SHOULDER
AP
75 250 0.04 10 Large 100 24 x 30 No
3.2
(>2.7)
28 16200 64.61 0.12
ELBOW AP 60 100 0.04 4 Small 100 24 x 30 No
3.8
(>2.1)
6.7 3992 39.7 0.075
WRIST PA 60 100 0.032 3.2 Small 100 24 x 30 No
3.8
(>2.1)
5.4 3982 39.4 0.063
HAND PA 60 100 0.032 3.2 Small 100 24 x 30 No
3.8
(>2.1)
5.4 4042 40 0.094
Combined standard uncertainty is
¦
35%
(IEC 60580:2000 / IEC 60601-2-54:2009
and IEC 60601-2-54:2009+AMD1:2015).
Note .
