AGFA DX-D 100 - Wireless DR Detector with Telescopic Column Specifications

DX-D 100 Mobile X-ray Unit
User Manual
0188K EN 20201116
81
6.3.2 MOBILE WITH WIRELESS DR DETECTOR AND TELESCOPIC COLUMN
LENGTH WIDTH HEIGHT WEIGHT
minimum 1313 mm
maximum 2560 mm
670 mm
minimum 1340 mm
maximum 2150 mm
580 kg
(without Detectors and/or Accessories)
¦180
o
Reception Area
Focal Spot
min. 702 / max. 1242
min.510 / max. 1050192
1275
1340
1150
1313
2410
max. 2560
< 530
max. SID > 2020
2150
Travel: > 1490
120
o
¦317
o
Focal Spot
Focal Spot
670
600
1340
Reference Axis
Dimensions in mm.
Tolerance in Dimensions ± 1%
¦180
o
¦90
o
120
o
