DX-D 100 Mobile X-ray Unit
User Manual
0188K EN 20201116
77
SECTION 6 TECHNICAL SPECIFICATIONS
6.1 FACTORS
Generator Model DX-D 100
Maximum Power kW
(Refer to Identification Label)
20 kW 32 kW 40 kW 50 kW
k
V
R
40 to 125
(40 to 150 optional)
40 to 150 40 to 150 40 to 150
kVp Range
From 40 kV to 125 kV or 150 kV in 1 kV steps.
(Depending on the Generator model)
mAs Range Product of mA x Time values from 0.1 mAs to 500 mAs
10 to 320 10 to 500 10 to 500 10 to 500
mA Range
From 10 mA to 320 or 500 mA through the following mA stations:
10, 12.5, 16, 20, 25, 32, 40, 50, 64, 80, 100, 125, 160, 200, 250, 320, 400, 500.
(Depending on the Generator model)
Exposure Time Range
From 1 millisecond to 10 seconds through the foll owing Time stations:
Milliseconds: 1, 2, 3, 4, 5, 6, 8, 10, 12, 16, 20, 25, 32, 40, 50, 64, 80,
100, 125, 160, 200, 250, 320, 400, 500, 640, 800.
Seconds: 1, 1.25, 1.6, 2, 2.5, 3.2, 4, 5, 6.4, 8, 10.
Power Output (@ 0,1s)
125 kVp @ 160 mA
100 kVp @ 200 mA
80 kVp @ 250 mA
62 kVp @ 320 mA
150 kVp @ 200 mA
128 kVp @ 250 mA
100 kVp @ 320 mA
80 kVp @ 400 mA
64 kVp @ 500 mA
150 kVp @ 250 mA
125 kVp @ 320 mA
100 kVp @ 400 mA
80 kVp @ 500 mA
150 kVp @ 320 mA
125 kVp @ 400 mA
100 kVp @ 500 mA
D
t
C
l
18 exposures per hour at maximum mAs (lapse time between exposures: 3 min.)
Duty Cycle
Maximum leakage radiation depends on the type of X-ray Tube (<0.88 mGy/h)
Collimator Manual with electronic timer and meter
X-ray Tube Refer to Section 6.2
