Analog Bandwidth - Maximum Frequency Check
Max frequency: DSO3062A = 60 MHz, DSO3102A = 100 MHz, DSO3152A = 150 MHz, DSO31202A = 200 MHz
Vin
@ 1 MHz
Vout
@ 1 MHz
Calculated
Gain @ 1 MHz
(Test Limit =
greater than -3
dB)
Vin
@ Max Freq
Vout
@ Max Freq
Calculated
Gain @ Max Freq
(Test Limit =
greater than -3
dB)
Channel 1
Channel 2
