Utility Controls
I/O Setup Menu
2-51
I/O Setup Menu
Before installing or uninstalling the I/O module, make sure that the oscilloscope
power is off. More details can be found in the Programmer’s Guide on the
CD-ROM.
Pressing the I/O Setup menu key produces the following menu.
Table 2-22
I/O Setup Menu
Requires the I/O module to be installed before the GPIB and RS-232 ports can be
configured.
Menu Settings Comments
RS-232 Baud 300
2400
4800
9600
19200
38400
Sets the RS-232 baud rate
GPIB Address 0 through 30 Sets the GPIB address
USB connected
To Next Page
