Agilent Technologies 3000 Series User Manual

Utility Controls
Mask Test
2-50
Table 2-21
Mask Test Menu 3
Menu Settings Comments
X Mask
< x div >
Set the mask’s horizontal failure margin (0.04 div to 4.00 div)
Y Mask
< y div>
Set the mask’s vertical failure margin (0.04 div to 4.00 div)
Create Mask Create a mask from the current waveform using the above failure
margins
Save Save the created mask
The Mask Test function is unavailable in X-Y mode .
The Output function is available on a BNC connector that is part of the optional I/O
module.
