Agilent Technologies 3000 Series User Manual

3-4
Specifications and Characteristics
Characteristics
Acquisition System
Max Sample rate 1 GSa/s
Vertical Resolution 8 bits
Peak Detection 5 ns
Averages selectable from 2, 4, 8, 16, 32, 64, 128, and 256
Vertical System
Analog channels Channels 1 and 2 simultaneous acquisition
DSO3062A: 60 MHz
DSO3102A: 100 MHz
DSO3152A: 150 MHz
DSO3202A: 200 MHz
Calculated rise time
(= 0.35/bandwidth)
DSO3202A: 1.8 ns
DSO3152A: 2.3 ns
DSO3102A: 3.5 ns
DSO3062A: 5.8 ns
Range
1
2 mV/div to 5 V/div
Maximum Input CAT II 1 MΩ 300 Vrms
Offset Range ±2 V 2 mV/div to 100 mV/div
±40 V on ranges 102 mV/div to 5 V/div
Input Resistance 1 M
Ω ±1%
Input Capacitance ~ 13 pF
Coupling AC, DC, ground
BW Limit ~ 20 MHz
ESD Tolerance ±2 kV
DC Vertical Gain Accuracy 2 mV/div to 5 mV/div: ±4%
10 mV/div to 5 V/div ±3%
DC Measurement
(≥
16 waveform averages)
±(3% x reading +0.1 div + 1mV) when 10 mV/div or greater is selected and vertical position
is at zero
±(3% x (reading + vertical position) + 1% of vertical position + 0.2 div) when 10 mV/div or
greater is selected and vertical position is not at zero
Add 2 mV for settings from 2 mV/div to 200 mV/div
Add 50 mV for settings > 200 mV/div to 5 V/div
