Primary and Secondary Display Functions
Primary Display
DCV
DCI
Resistance
Default Secondary
Display
Press Once Press Twice
Secondary Display
DCV Range ACV Off
DCI Range ACI Off
Resistance Range Off Resistance Range
ACV
ACI
Frequency
ACV Range Frequency Off
ACI Range Frequency Off
AC Voltage Range ACV Off
Capacitance Capacitance Range Off Capacitance Range
Diode Test Off Off Off
Continuity Off Off Off
Temperature Off Off Off
Disp
Disp
8. Using the Secondary Display
When making measurements, the secondary display allows you to show the measurement
range (for most measurement functions) or to select a predefined secondary
measurement function. You may have already noticed the secondary display showing
Auto for autorange when changing measurement functions:
As another example, a typical primary display showing ACV and a secondary display
showing the measured frequency of the input signal is:
The secondary display is based on the selected primary measurement function and how
many times you press:
The table below shows the secondary display capabilities for all measurement functions.
Disp
mV DC
V AC
Hz
