Agilent Technologies 3458A Repair Manual

Chapter 3 Disassembly/Assembly Procedures and Parts List 65
0515-1404 3 4 Screw-mach M4 x 0.7
55MM-LG PAN-HD
93907 Order by Description
MP1 03458-60201 03458-40211 1 Assembly-front panel 28480
03458-40202 03458-40212 1 Panel (front) 28480
03458-69302 03458-69312 1 Window 28480
03458-81902 03458-81912 1 Keypad 28480
MP2 5041-8802 5041-9176 1 Trim (top front bezel) 28480
MP3 03458-04101 03458-04111 1 Cover-top 28480
MP4 0515-0372 2 1 Screw-machine assembly
M3 x 0.5 8MM-LG
93907 Order by Description
MP5 5001-0538 5041-9170 2 Trim strip 28480
MP6 5062-3704 5063-9210 2 Strap-handle 28480
MP7 5041-8819 5041-9186 2 Cap, strap handle (front) 28480
MP8 5041-8820 5041-9187 2 Cap, strap handle (rear) 28480
MP9 0515-1132 4 4 Screw-mach M5 x 0.8
10MM-LG
N/A Order by Description
MP10 03458-00601 1 1 Shield-top 28480 03458-00601
MP11 0515-1604 5 2 Screw-mach M3.5 x 0.6
6MM-LG
93907 Order by Description
MP12 03458-00106 1 1 Chassis-mainframe 28480 03458-00106
MP13 03458-47901 03458-47911 1 Bezel-rear 28480
MP14 1390-0793 6 4 Fastener-captive screw
M4X 0.7 THD 9.0
N/A Order by Description
B1 03458-68501 2 1 Assembly-fan 28480 03458-68501
MP15 0624-0530 5 2 Screw-TPG 8-16
.375-IN-L6
PAN-HD-TORX
93907 Order by Description
MP16 3150-0300 5 1 Filter-air nylon 2.3-IN-OD
.75-IN-LG
N/A Order by Description
MP17 0515-0372 2 2 Screw-machine assembly
M3 x 0.5 8MM-LG
93907 Order by Description
MP18 03458-00602 2 1 Shield-bottom 28480 03458-00602
MP19 0515-1604 5 2 Screw-mach M3.5 x 0.6
6MM-LG
93907 Order by Description
MP20 03458-04102 03458-04112 1 Cover-bottom 28480
MP21 0515-0372 2 1 Screw-machine assembly
M3 x 0.5 8MM-LG
93907 Order by Description
MP22 5041-8801 5041-9167 4 Foot 28480
MP23 1460-1345 5 2 Tilt-stand SST N/A Order by Description
03458-84302 03458-84312 1 Label (rear panel) 28480
03458--84303 03458-84313 1 Label (front panel) 28480
03458-67902 03458-67912 2 Fuseholder (current trmnl) 28480
03458-62101 03458-62111 2 Terminal block assy 28480
03458-44105 03458-44115 2 Terminal block assy
insulator cover
28480
Table 7. 3458A Replaceable Parts
Ref
Desig
Agilent Part Number
for Old Case Colors
Agilent Part Number
for New Case Colors
C
D
Qty Description Mfr
Code
Mfr Part Number
