Agilent Technologies 3458A Repair Manual

Chapter 4 Assembly Level Troubleshooting 79
204 Atten HF DAC
Convergence
AC Converter A2 03458-66502
204 AC AMP HF DAC
Convergence
AC Converter A2 03458-66502
204 Interpolator Level
Seek
A/D Converter and
Inguard Logic
A3 03458-66503
204 Interpolator DAC
Convergence
A/D Converter and
Inguard Logic
A3 03458-66503
204 Reference Control
Loop Failure
A/D Converter and
Inguard Logic
A3 03458-66503
205 Test Value Out of
Range
See text
206 HPIB Outguard Controller A5 03458-66505
A5 03458-66515
206 HPIB ASM Outguard Controller A5 03458-66505
A5 03458-66515
207 UART Outguard Controller A5 03458-66505
A5 03458-66515
207 UART INTR Outguard Controller A5 03458-66505
A5 03458-66515
208 Timer Outguard Controller A5 03458-66505
A5 03458-66515
208 Timer INTR Outguard Controller A5 03458-66505
A5 03458-66515
210 ROM 0 LOW
CHECKSUM
Outguard Controller A5 03458-66505
A5 03458-66515
210 ROM 1 LOW
CHECKSUM
Outguard Controller A5 03458-66505
A5 03458-66515
210 ROM 2 LOW
CHECKSUM
Outguard Controller A5 03458-66505
A5 03458-66515
211 ROM 0 HIGH
CHECKSUM
Outguard Controller A5 03458-66505
A5 03458-66515
211 ROM 1 HIGH
CHECKSUM
Outguard Controller A5 03458-66505
A5 03458-66515
211 ROM 2 HIGH
CHECKSUM
Outguard Controller A5 03458-66505
A5 03458-66515
212 NONVOLATILE RAM
HIGH
Outguard Controller A5 03458-66505
A5 03458-66515
212 NONVOLATILE RAM
LOW
Outguard Controller A5 03458-66505
A5 03458-66515
213 Optional RAM 0 High Outguard Controller A5 03458-66505
A5 03458-66515
214 Optional RAM 0 Low Outguard Controller A5 03458-66505
A5 03458-66515
214 Optional RAM 1 High Outguard Controller A5 03458-66505
Table 9. Self-Test Error Messages and Probable Causes
Error
Number
Error Message Probable Cause Ref
Desig
Assembly
Part Number
