Agilent Technologies 54831A Service Guide

Chapter 7: Replaceable Parts
Replaceable Parts List
7–11
Replaceable Parts
Ref.
Des.
Agilent Part
Number QTY Description
Exchange Assemblies
A1 54830-66505
or
54830-66407
1 2-CH ACQUISITION ASSEMBLY (Agilent Model 54830B requires software
version Windows 98 2.35 or XP 3.5 or later)
All others require this assembly.
A1 54831-66505
or
54831-66407
1 4-CH ACQUISITION ASSEMBLY (Agilent Model 54831B requires software
version Windows 98 2.35 or XP 3.5 or later)
All others require this assembly.
A1 54832-66505
or
54832-66406
1 4-CH ACQUISITION ASSEMBLY (Agilent Model 54832B requires software
version Windows 98 2.35 or XP 3.5 or later)
All others require this assembly.
A1 54836-66502
or
54830-66406
1 2-CH ACQUISITION ASSEMBLY (Agilent Model 54830D requires software
version Windows 98 2.35 or XP 3.5 or later)
All others require this assembly.
A1 54837-66502
or
54831-66406
1 4-CH ACQUISITION ASSEMBLY (Agilent Model 54831D requires software
version Windows 98 2.35 or XP 3.5 or later)
All others require this assembly.
A1 54838-66502
or
54832-66407
1 4-CH ACQUISITION ASSEMBLY (Agilent Model 54832D requires software
version Windows 98 2.35 or XP 3.5 or later)
All others require this assembly.
A1 54833-66501
or
54833-66407
1 2-CH ACQUISITION ASSEMBLY (Agilent Model 54833A requires software
version Windows 98 2.35 or XP 3.5 or later)
All others require this assembly.
A1 54833-66502
or
54833-66406
1 2-CH ACQUISITION ASSEMBLY (Agilent Model 54833D requires software
version Windows 98 2.35 or XP 3.5 or later)
All others require this assembly.
External Chassis Parts
MP13 54801-47403 1 KNOB 24 MM GRAY
MP14 54801-47408 1 KNOB 18 MM YELLOW
MP15 54801-47404 1 KNOB 12 MM YELLOW
MP16 54801-47409 1 KNOB 18 MM GREEN
MP17 54801-47405 1 KNOB 12 MM GREEN
MP18 54801-47410 1 KNOB 18 MM PURPLE
MP19 54801-47406 1 KNOB 12 MM PURPLE
MP 20 54801-47411 1 KNOB 18 MM PINK
MP21 54801-47407 1 KNOB 12 MM PINK
MP22 54801-47401 4 KNOB 12 MM GRAY
MP26 54832-94330 1 FRONT PANEL 4-CH LABEL (54831/32B)
MP26 54830-94330 1 FRONT PANEL 2-CH LABEL (54830B, 54833A)
MP26 54838-94330 1 FRONT PANEL 4-CH LABEL (54831/32D)
MP26 54836-94330 1 FRONT PANEL 2-CH LABEL (54830D, 54833D)
MP28 54831-94303 1 LOGO LABEL (54831M)
MP28 54830-94308 1 LOGO LABEL (54830B)
MP28 54831-94308 1 LOGO LABEL (54831B)
MP28 54832-94308 1 LOGO LABEL (54832B)
MP28 54832-94309 1 LOGO LABEL (54832D)
MP28 54931-94309 1 LOGO LABEL (54831D)
MP28 54830-94309 1 LOGO LABEL (54830D)
MP28 54833-94302 1 LOGO LABEL (54833A)
MP28 54833-94301 1 LOGO LABEL (54833D)
MP31 54810-68701 1 ACCESSORY POUCH
MP32 5042-1798 2 REAR FEET
MP34 54810-44901 1 MOLD OVER HANDLE
