Agilent Technologies 54831A Service Guide

Chapter 7: Replaceable Parts
Replaceable Parts List
7–12
MP
35 54810-45001 2 END CAP HANDLE
MP36 54810-61001 4 BOTTOM FEET w/INSERT
MP37 54810-03702 1 TILT STAND
MP38 01680-41002 4 SIDE FOOT
W18 8120-1521 1 CABLE-POWER (standard 125V USA)
W18 8120-1703 1 CABLE-POWER (Option 900-UK)
W18 8120-0696 1 CABLE-POWER (Option 901-AUSTL)
W18 8120-1692 1 CABLE-POWER (Option 902-EUR)
W18 8120-2296 1 CABLE-POWER (Option 906-SWIT)
W18 8120-2957 1 CABLE-POWER (Option 912-DEN)
W18 8120-4600 1 CABLE-POWER (Option 917-AFRICA)
W18 8120-4754 1 CABLE-POWER (Option 918-JAPAN)
W18 8120-6799 1 CABLE-POWER (Option 919-ISRAEL)
W18 8120-6871 1 CABLE-POWER (Option 920-ARGENTINA)
W18 8120-6979 1 CABLE-POWER (Option 921-CHILE)
W18 8120-8377 1 CABLE-POWER (Option 922)
W18 8120-8871 1 CABLE-POWER (Option 927-THAILAND)
Electrical Assemblies
A2 0950-4191 1 POWER SUPPLY
A5 0950-3235 1 INVERTER BOARD
A13 2090-0396 1 LCD DISPLAY
PC Motherboard
A4 86100-66517
54810-66541
1 CDROM ADAPTER BOARD (NOT ON OPTION 017)
CDROM ADAPTER BOARD (WITH OPTION 017)
A6 0950-4373 1 CD ROM Drive
A7 0950-4362 1 1.44 FLOPPY DRIVE
A8 1 HARD DRIVE with SOFTWARE (NOT ON OPTION 017)
Go to the web site to find the hard drive part number:
www.agilent.com/find/infiniium_software
A19 0960-2481 1 MOTHERBOARD SUBASSEMBLY
W13 54801-61643 1 HARD DRIVE MINI IDE CABLE (NOT ON OPTION 017)
W14 54810-61615 1 HARD DRIVE GROUND CABLE (NOT ON OPTION 017)
W15 54810-61611 1 IDE HARD DRIVE CABLE
All Configurations
A9 54810-66506 1 PROBE INTERFACE BOARD
A11 54810-66529 1 GRAPHICS BOARD
A12 54810-66525 1 DISPLAY BOARD
A16 54830-68703
0
2-CH REPLACEMENT I/O KIT (54830B, 54833A)
A16 54832-68703
0
4-CH REPLACEMENT I/O KIT (54831B/32B)
A16 54838-68703
0
4-CH REPLACEMENT I/O KIT (54831/32D)
A16 54836-68701
0
2-CH REPLACEMENT I/O KIT (54830D, 54833D)
A17 54826-66507 1 KEYBOARD - CURSOR
A18 54832-66504 1 KEYBOARD - 4CH (54831/32B)
A18 54830-66504 1 KEYBOARD - 2CH (54830B, 54833A)
A18 54826-66504 1 KEYBOARD - 4CH (54831/32D)
A18 54831-66504 1 KEYBOARD - 2CH (54830D, 54833D)
Replaceable Parts
Ref.
Des.
Agilent Part
Number QTY Description
