Chapter 7: Replaceable Parts
Replaceable Parts List
7–13
A20 5
4810-66545
1
FAN CONTROLLER BOARD
A21 54855-66515
1
INTERFACE & GPIB BOARD
A22 0950-4113
1
DC TO DC COVERTOR BOARD
Fans
B1 3160-4134 6 12 V FAN
Internal Chassis Parts
H1 0515-2219 3 MACHINE SCREW 5 MM
H2 54503-25701 3 HEX NUT BNC (54830/33)
H2 54503-25701 4 HEX NUT BNC (54831/32)
H3 0515-1025 3 PAN HEAD SCREW 26 MM
H4 0515-1410 4 PAN HEAD SCREW 20 MM
H5 0515-0430 11 PAN HEAD SCREW 6 MM
H6 0515-0372 22 PAN HEAD SCREW 8 MM
H7 0515-1246 2 PATCH LOCK SCREW 6 MM
H8 5021-4302 4 M4x0.7 20MM-LG PANHD PATCHLOCK BLACK
H9 54801-24702 1 RETAINER STRAP HANDLE
H10 0515-2195 4 PAN HANDLE SCREW 40 MM
H11 0515-1103 10 FLAT HEAD SCREW
H12 0515-0380 17 PAN HEAD SCREW
H13 0515-1403 4 M4X0.7 6 MM 90DEG FLATHD T15
H14 0515-0436 4 MS M4X0.7 18 MM LG SCREW (NOT ON OPTION 017)
H15 0515-0375 3 MS MSX0.5 16 MM LG
H16 0515-0365 6 SCR MACHINE
H18 0515-2691 2 MS M2.6X0.45 6 MM PAN HEAD
MP1 0624-1066 24 FAN SCREWS
MP2 54832-04105 1 SLEEVE BOTTOM
MP3 54830-00105 1 CHASSIS ASSEMBLY
MP4 54857-60102 1 ATX TRAY
MP5 54810-01211 1 HARD DRIVE BRACKET (NOT ON OPTION 017)
MP7 54857-01214 1 CDROM MOUNT BRACKET
MP8 54832-04103 1 FRONT FRAME BACK PLATE
MP9 54832-40501 1 FRONT FRAME (54830/31/32/33D)
MP10 54810-01213 1 POWER SUPPLY SUPPORT BRACKET
MP11 54826-88001 1 LENS GLASS
MP12 54826-01205 1 LENS BRACKET
MP25 54801-09101 2 SPRING STEEL
MP27 54831-41903 1 KEYPAD 4-CH (54831/32B)
MP27 54830-41905 1 KEYPAD 2-CH (54830B/33A)
MP27 54831-41901 2 KEYPAD 4-CH (54831/32D)
MP27 54830-41904 1 KEYPAD 2-CH (54830D/33D)
MP29 54826-41902 1 CURSOR KEYPAD
MP33 54810-04104 1 SLEEVE TOP
MP39 1520-0238 4 GROMET (NOT ON OPTION 017)
MP40 54857-60201 1 REMOVEABLE HARD DRIVE COVER PLATE (NOT ON OPTION 017)
MP41 54857-01216 1 REMOVEABLE HARD DRIVE BRACKET (WITH OPTION 017)
MP42 1252-7017 4 RETAINER CLIP
MP43 54826-01207 1 DC-TO-DC CONVERTER BRACKET
Replaceable Parts
Ref.
Des.
Agilent Part
Number QTY Description
