Chapter 3: Testing Performance
To verify threshold accuracy
3–31
Band
width Down from reference: Channel 1 Channel 2 Channel 3 Channel 4
Equivalent Time <3.0 dB at 600 MHz
(54830/31B/D)
<3.0 dB at 1 GHz (54832B/D
& 54833A/D)
___________
___________
___________
___________
___________
___________
___________
___________
Bandwidth
(Cont’d)
Real Time
Agilent
54830/31B/D
54832B/D & 54833A/D
<3.0 dB at 600 MHz
<3.0 dB at 1 GHz
___________ ___________ ___________ ___________
Time
measurement
accuracy —
equivalent time
mode
∆Time Limits Minimum Maximum
25 ns 24.957 to 25.043 ns __________________ __________________
10 ns 9.957 to 10.043 ns __________________ __________________
50 ns 49.72 to 50.28 ns __________________ __________________
1 µs 0.9975 to 1.0025 µs __________________ __________________
5 µs 4.9974 to 5.0026 µs __________________ __________________
Time
measurement
accuracy —
real time mode
Period Limits
39.5 ns 39.298 to 39.702 ns __________________ __________________
∆Time(edge#11) Limits
395 ns 394.780 to 395.220 ns __________________ __________________
∆Time (edge#101) Limits
3.94999 µs 3.94959 to 3.95039 µs __________________ __________________
∆Time (edge#201) Limits
7.89998 µs 7.89938 to 7.90057 µs __________________ __________________
Trigger
Sensitivity
Mode Stable Trigger On: Pass/Fail
Internal Trigger Channel 1 Channel 2 Channel 3 Channel 4
0.5 div at 100 MHz ___________ ___________ ___________ ___________
1.0 div at 500 MHz ___________ ___________ ___________ ___________
54830/31B/D only 1.5 div at 600 MHz ___________ ___________ ___________ ___________
54832B/D & 54833A/D
only
1.5 div at 1 GHz ___________ ___________ ___________ ___________
External Trigger (Agilent 54830B/D & 54833A/D only)
on ±1 V range: 45 mV
pp
at 100 MHz __________________
90 mV
pp
at 500 MHz __________________
Auxiliary Trigger (Agilent 54831/32B/D only)
300 mV
pp
at 500 MHz __________________
Test Limits Results
